5702269-C Specifications 3-3
Pinnacle™ Plus+ 10 kW
PHYSICAL SPECIFICATIONS
Cooling
Air-cooled
Fault Conditions
Several fault conditions will either cause the
Pinnacle Plus+ supply to shut off output or
prevent output from being turned on. These
conditions include open interlock loops, input
power failure, over-temperature, and user-
controlled timers.
Table 3-1. Functional Specifications (Continued)
Table 3-2. Physical Specifications
Size
133 mm (H) x 483 mm (W) x 639 mm (D),
including connectors
(5.22 in (H) x 19 in (W) x 25.18 in (D))
Weight
30 kg (66 lb)
Output Connector
Two terminal, multi-contact, pluggable connector
or UHF connector
Output Power Cable
For optimal performance, it is recommended that
you use an output power cable 3.05 m (10´) in
length—or shorter.
Note: The output power cable must not exceed 10
m (32.8´) or you may damage your power
supply.
Input Power Connector
Five terminal, DIN compression terminal block.
Maximum wire size #6AWG
User Port Connector
Please reference the “I/O Communication and
Control” chapter.
Serial (Host) Port
Connector
Please reference the “I/O Communication and
Control” chapter.
