5-14 Installation 5702269-C
Advanced Energy
®
MASTER/SLAVE PULSE PORT CABLE
Figure 5-9. Master/Slave Pulse port cable
Configuring Your Master Unit
Note: See Figure 5-10 on page 5-16 for an illustration.
To configure the master unit:
1. Remove all input power from the master and slave units.
7
6 PON-MSP Return Pulse On signal return
8
Cable shield SYNC_POWER_SENSE Verifies all units have
logic control power
9
n/a unassigned unassigned
10
n/a unassigned unassigned
11
12 OC-MSP Overcurrent signal
12
11 OC-MSP Return Overcurrent signal
return
13
14 OV-MSP Overvoltage signal
14
13 OV-MSP return Overvoltage signal
return
15
n/a unassigned unassigned
Table 5-1. Master/Slave Pulse Port Pin and Signal Descriptions
Pin Associated
Pin
Pin Name Description
15" lead
5" lead
