4-32 I/O Communication and Control 5702269-C
Advanced Energy
®
HOST, LOCAL, and USER options appear. Press one of these buttons to toggle
between internal and external for that types.
2. Press EXIT.
Note: A user card must be installed in order to alter these settings.
Setting the Panel Mode
SUPPLY → PANEL
Use this option to select between a remote and local control panel, lock the control
panel, set the lock code, or set the encoder rate for the knob clicks.
SELECTING REMOTE OR LOCAL MODE
SUPPLY → PANEL→ SELECT
To switch between the remote active panel and the local active panel:
1. Press SUPPLY → PANEL → SELECT.
2. Rotate the MODIFY knob to display YES or NO, depending on whether or not
you want to switch to a remote/local active panel.
3. Press ENTER to accept and exit.
4. Wait several seconds for verification of switch before using the other control
panel.
SELECTING A LOCK CODE
SUPPLY → PANEL→ LOCK
To enter a lock code for locking the active control panel:
1. Press SUPPLY → PANEL → LOCK.
4
SET CODE and LOCK UNIT options appear.
2. To set a lock code, press the SET CODE soft key. If a code is already entered,
press LOCK UNIT.
4
Any further menu accesses will require entry of the code.
Note: Cycling power on the supply resets the lock status to UNLOCKED.
SELECTING THE NUMBER OF CLICKS
SUPPLY → PANEL→ CLICKS
