4-22 I/O Communication and Control 5702269-C
Advanced Energy
®
Figure 4-7. Control panel main menu functions
As you press soft keys and move through the menu levels, the top line of the output
display screen displays the path of the menu in the upper, left-hand corner of the
display screen.
A parameter flashes if it can be modified; make such modifications with the MODIFY
knob. Pressing the ENTER soft key enters the modification into nonvolatile memory.
You can press the MODIFY knob at any time to cancel what you are doing (leave the
parameter(s) unchanged) and return to the output display screen.
If a fault exists or the panel is locked, the soft keys are locked out until you clear the
fault. See “Troubleshooting and Global Customer Support” on page -1 for a list of
fault messages.
UNDERSTANDING THE MENU OPTIONS
Pressing the rightmost soft key will bring up the main menu tree. When at the top
level, you have three menu options:
•Service
• Supply
• Process
From the Service menu, you can access diagnostic information. From the Supply
menu, you can modify supply-specific parameters, and from the Process menu, you
can access options that affect your process or monitor your process. To select a menu
option, press the soft key below the menu option. See the menu maps for a graphical
representation of the menu options.
SERVICE SUPPLY PROCESS
