5702269-C Installation 5-5
Pinnacle™ Plus+ 10 kW
MAKING REAR PANEL CONNECTIONS
Grounding
For your convenience, the rear panel of the Pinnacle Plus+ 10 kW supply features
three equi-potential ground studs: two M5 studs and a 10-32 stud. These are indicated
on the rear panel by a ground symbol.
Note: You must ground the power supply as specified by the conditions of use. See
“Conditions of Use” on page 1-6
for more information.
Note: For optimal performance, ground an equi-potential ground stud to the system
ground.
Connecting a Pinnacle Remote Active Panel
Connections for an Advanced Energy Pinnacle Remote Active Panel are made
through a 9-pin, male, subminiature-D connector labeled REMOTE on the rear panel.
See the “I/O Communication and Control” chapter.
Note: To reduce EMI interference, we recommend using shielded cable to connect to
the Remote Active Panel port.
RISK OF DEATH OR BODILY INJURY. Disconnect all sources of input
power before working on this unit or anything connected to it.
Do not apply RF power directly to the output of the Pinnacle Plus+
unit. Damage to the Pinnacle Plus+ unit could result. If you are using
both an RF power supply and a Pinnacle Plus+ supply in the same
system, include an RF filter in the system.
Before making any other connection, connect one of the equi-potential
ground studs to earth ground.
