3-10 Specifications 5702269-C
Advanced Energy
®
Reverse Time As A Function of Voltage Limit
Note: Not all Pinnacle Plus+ units are shipped with reverse time as a function of
voltage limit. This is a special feature that your power supply must be
configured for at the factory.
Some processes require that the Pinnacle Plus+ power supply allow a longer duration
when reversing the voltage. By utilizing the V-Limit function of your power supply,
you may be able to increase the reverse time to a maximum of 10 µs (when voltage is
limited to 325 V). When the unit is set for 650 V (or higher in Hi-Z models), the
maximum reverse time is 5 µs. As you decrease process voltage using the V-Limit
function, the reverse time increases linearly until it reaches the maximum allowable
value of 10 µs.
Note: The maximum reverse time duty cycle is still 45%.
Figure 3-2 on page 3-11 is a graph of pulse reversal times as a function of the user
voltage limit. Table 3-5 on page 3-11 provides a detailed list of reverse times and the
corresponding user voltage limit.
310
307.692 1.3 12.31 40
315
312.5 1.2 12.50 37.5
320
317.46 1.2 12.70 38.1
325
322.581 1.2 12.90 38.7
330
327.869 1.2 13.11 39.3
335
333.333 1.2 13.33 40
340
338.983 1.1 13.56 37.3
345
344.828 1.1 13.79 37.9
350
350.877 1.1 14.04 38.6
Table 3-4. Reverse Time Given a Self-Run Frequency (Continued)
Requested
Frequency
(kHz)
Actual
Frequency
(kHz)
Pulse
Reversal Time
Maximum (µs)
Duty Cycle
(min%)
Reverse/
Period
Duty Cycle
(max%)
Reverse/
Period
