Advanced Energy Pinnacle Plus+ - Module Status LED; Table 4-5. MOD Status LED

5702269-C I/O Communication and Control 4-11
Pinnacle™ Plus+ 10 kW
MODULE STATUS LED
The MOD bi-color (amber/green) LED provides device status. It indicates whether
the device has power and is operating properly. The following table shows the LED’s
various states and their meanings.
For information on LED flash rates, refer to section 8.2.8 of the DeviceNet
Specification (revision 2.0).
For information about Module Status LED indications during power-up, refer to
Section 8.2.4 of the DeviceNet Specification (revision 2.0).
Table 4-5. MOD Status LED
If the LED is the state indicated is which means that
Off
No power the unit is not receiving
power.
Green (steady)
Operational the unit is operating
normally.
Flashing Green
Standby the unit needs
maintenance because the
configuration is missing,
incomplete, or incorrect.
Amber
Unrecoverable Fault the unit has experienced a
fault from which it
cannot recover; you may
need to replace the unit.
Flashing Amber/
Green
Device Self-Testing the unit is running self
diagnostics
