5702269-C I/O Communication and Control 4-1
Chapter
Pinnacle™ Plus+ 10 kW
Chapter
4
I/O Communication and Control
USER PORT
The User port allows you to control the Pinnacle unit through a remote controller. The
connector is a 15-pin, subminiature-D, female connector (see the following
illustration).
Figure 4-1. 15-pin User port
You may operate the Pinnacle unit solely through the 15-pin User port. User port
operation does not require connection to a DeviceNet network.
