To connect your Pinnacle Plus+ power supply to the Pinnacle Remote Active
Panel:
1. Connect the cable between the REMOTE ACTIVE PANEL connector on the
Pinnacle Plus+ supply and the Pinnacle Remote Active Panel.
Understanding the Panel
CONTROL KEY
To control your Pinnacle Plus+ supply from the panel, select local mode by pressing
the CONTROL key on the panel until the LOCAL LED lights. Placing the unit in
local mode gives you full access to the front panel menu (see “Control Panel
Interface” on page 4-18).
To control the Pinnacle Plus+ supply from the Serial interfaces or the DeviceNet port,
press the CONTROL key until the HOST LED lights. To control the Pinnacle Plus+
supply from the User port, press the CONTROL key until the USER LED lights.
When the Pinnacle Plus+ unit is in host or user control mode, you can view all the
menu items, but you cannot modify parameters or lock the display.
OUTPUT DISPLAY SCREEN
The first screen that appears on the panel's vacuum fluorescent display when you
power up is the “output display screen.” See “Two-Line Output Display Screen” on
page 4-19 for more information.
Viewing Output Information
The output display screen shows the actual output level in volts, amps, and watts. (See
the front panel drawings at the end of the “Installation” chapter.) It also displays the
set point.
Selecting Set Point
To program the set point level from an active control panel, use the panel's
CONTROL key to select local control mode (the LOCAL LED will light). (See
“Setting Control Parameters” on page 4-40.) Activate the set point value, then turn the
MODIFY knob until the set point you want is displayed, then deactivate the set point
value.
8
R-
9
R+
Table 4-8. Remote Panel Pin Descriptions (Continued)
Pin Description
To Next Page
