Table 4-15. AE Bus Address Settings
Address A4 A3 A2 A1 A0
0
Don't assign this address to a unit; it is the AE Bus broadcast
address—all Pinnacle Plus+ units receive a message sent to this
address by the host, but will not reply.
1 upupupupdown
2 upupupdownup
3 upupupdowndown
4 up updownup up
5 up updownupdown
6 up up down down up
7 up up down down down
8 updownupupup
9 updownup updown
10 up down up down up
11 up down up down down
12 up down down up up
13 up down down up down
14 up down down down up
15 up down down down down
16 down up up up up
17 down up up up down
18 down up up down up
19 down up up down down
20 down up down up up
21 down up down up down
22 down up down down up
23 down up down down down
24 down down up up up
25 down down up up down
26 down down up down up
27 down down up down down
28 down down down up up
