5702269-C Installation 5-1
Chapter
Pinnacle™ Plus+ 10 kW
Chapter
5
Installation
UNPACKING
Unpack and inspect your power supply carefully. Check for obvious physical damage.
If no damage is apparent, proceed with the unit connections. If you do see signs of
shipping damage, contact Advanced Energy Industries, Inc., and the carrier
immediately. Save the shipping container for submitting necessary claims to the
carrier.
MEETING SPACING REQUIREMENTS
See Figure 5-2 on page 5-4 for a graphical representation of the spacing requirements.
• The clearance between either side of the Pinnacle Plus+ supply and the enclosure
must be 76 mm (3 in).
• The clearance between the top of the Pinnacle Plus+ supply and the top of the
enclosure must be 25 mm (1 in).
• No clearance is required between power supplies.
• The clearance between the rear of the Pinnacle Plus+ supply and the enclosure
must be 102 mm (4 in), with adequate ventilation.
