Advanced Energy Pinnacle Plus+ - AE Bus Communications; Setting Baud Rates and Communication Mode; Table 4-17. Baud Rate Settings

5702269-C I/O Communication and Control 4-53
Pinnacle™ Plus+ 10 kW
SETTING BAUD RATES AND COMMUNICATION MODE
Also use the DIP switch (see Figure 4-13 on page 4-49 and Figure 4-14 on page 4-49)
to set the baud rate for the AE Bus port. The following tables show the DIP switch
settings for BR0, BR1, and Switch 8. Switch 8 sets the supply to either RS-232 or RS-
485/422. Switches BR0 and BR1 set the baud rates.
AE BUS COMMUNICATIONS
The following sections describe communications between a host and the Pinnacle
Plus+ supply.
29 down down down up down
30 down down down down up
31 down down down down down
Table 4-16. Setting Switch 8
Switch Position Communication Mode
Up RS-232
Down RS-485/422
Table 4-17. Baud Rate Settings
Baud Rate
RS-232
Baud Rate
RS-485/422
BR0 BR1
1200 9600 up up
4800 19,200 up down
9600 38,400 down up
19,200 57,600 down down
Table 4-15. AE Bus Address Settings (Continued)
Address A4 A3 A2 A1 A0
