4. Press EXIT to exit.
Note: You may press RESET at any time at this menu level to clear the arc counters.
SETTING THE ARC SHUTDOWN TIME
PROCESS → ARC → TIME
To set the arc shutdown time:
1. Press PROCESS → ARC → TIME.
2. Press the soft key under A/B to select side A or B. An arrow displays next to the
letter of the side that is currently selected.
3. Rotate the MODIFY knob to select the arc shutdown value (in microseconds).
4. Press ENTER to save your selection and exit.
ENABLING ARC HANDLING
PROCESS → ARC → ENABLE
This function enables or disables the arc handling functions of the Pinnacle Plus+
supply.
To disable the arc handling:
1. Press PROCESS → ARC → ENABLE.
2. Select Yes or No for MICRO arc handling.
3. Press ENTER to accept and exit.
Note: As an inherent safety feature, cycling power to the unit resets arc handling to
enabled.
Note: Hard arc handling is always enabled.
Setting Control Parameters
PROCESS → CONTROL
Default at power up is micro and hard arc handling enabled. If you
choose to disable micro arc handling, your Pinnacle Plus+ unit will not
respond to micro arcs, which could potentially affect your process. You
cannot disable hard arc handling.
