5702269-C I/O Communication and Control 4-83
Pinnacle™ Plus+ 10 kW
161
request
output on
status
Requests the Control Status Response (CSR) of
most recent output on sequence; the returning
packet contains 1 data byte (8-bit value):
• 0 = Output on sequence OK.
• 1 = Control mode invalid
• 2 = Unit is already on
• 7 = Active fault exists
• 11 = Bus is not ready
• 16 = End of target life event
• 17 = Minimum off time is active
• 31 = User port reset line active
• 32 = Contactor is open due to a fault
condition
• 44 = The Pinnacle Plus+ has not received
a request to turn output on since power up
Note: See “Understanding Command Status
Response (CSR) Codes” on page 4-57
for more information on CSR codes.
01
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
