Advanced Energy Pinnacle Plus+ - Page 133

5702269-C I/O Communication and Control 4-89
Pinnacle™ Plus+ 10 kW
170
request arc
shutdown
Requests the arc shutdown time. The returning
packet contains 2 data bytes.
• Byte 1 = Unused
• Byte 2 = Index value set with command 8
(refer to command 8 for the shutdown
index values).
02
171
request
voltage arc
trip level
Requests the index for the voltage level at
which the unit indicates an arc is occurring. For
a list of the voltage levels indicated by the
index values, see command 10 text. The
returning packet contains 1 data byte indicating
the trip level index.
This value is set with command 10.
01
172
request
joules
remaining
Requests how many joules remain during a
run; the returning packet contains 4 data bytes
(32-bit value) indicating the number of joules.
04
173
request
joules set
point
Requests the joules set point; the returning
packet contains 4 data bytes (32-bit value)
indicating the set point level in joules.
This value is set with command 4.
04
174
request over-
voltage timer
value
Requests the over-voltage timer value; the
returning packet contains 2 data bytes (16-bit
value) indicating the value.
This value is set with command 34.
02
175
request time
output on
Requests how much time has elapsed since
output power was turned on; the returning
packet contains 3 data bytes:
• First byte = Number of hours
• Second byte = Number of minutes
• Third byte = Number of seconds
03
Table 4-19. AE Bus Commands (Continued)
Command Description Number
of
Transmit
Data
Bytes
CSR
Codes or
Number of
Response
Bytes
Page 133 of 204
Ex. 1024 Page 133
