Clearing Faults in a Sync Pulse System
The following table describes some of the errors you might encounter with a Pinnacle
Plus+ master/slave system.
Note: For more information about error codes, please refer to the “Troubleshooting”
chapter.
Table 5-4. Errors Associated With The Pinnacle Plus+ Sync Pulse System
Condition Possible Cause(s)
Transmit unit reports:
“Multiple Sync Pulse
Transmitters Detected”
• Two or more units have been designated as
transmitters.
Note: Multiple transmitter errors are detected
only at power up or when changing port
directions.
Receive unit reports:
“No Sync Pulse
Transmitter Detected”
• The sync pulse cable has been removed.
• All units in the system are designated as receivers.
Note: No transmitter errors are detected any time
the unit is powered up.
Any unit reports:
"System Input Power
Fault"
• One of the units in the system is not energized (that
is, does not have input power).
