5702269-C Specifications 3-5
Pinnacle™ Plus+ 10 kW
Output Accuracy
Accuracy of actual output value to set point at
25ºC is ±1% of the actual value (V, kW, or A) or
±0.2% of the full rated output (whichever is
greater) for the full input voltage range and within
the output impedance range
Load Regulation
±1% for 4:1 load change within V-I limits of tap
Line Regulation
±1% for 10% line voltage change or ±2%
frequency change
Repeatability
Output power repeatability from run to run at a
constant set point is 0.1% from 10% to 100% of
rated power.
Temperature Coefficient
<0.015%/°C (<150 ppm/°C) variation in the
regulated output parameter over 20°C to 40°C
ambient temperature range
Output Ripple Voltage
(360 Hz / 300 Hz)
The component of output voltage ripple as related
to input line frequency is less than 2% rms.
Accuracy of All Analog
Signals
±1% of the actual value (V, kW, or A) or ±0.2% of
the full scale value, whichever is greater
Power Factor
> 0.95 for 10 kW
Standard Output Range
(full power)
10 kW over the 325-to-650-Vdc range in DC
mode, with a maximum current of 30.8 A
Note: Output is measured at the DC inverter
output (see Figure 2-1 on page 2-2).
Note: Do not use an output cable longer than 32.8
feet (10 m).
Usable Output Range
See Figure 3-3 on page 3-14.
Impedance Range
See Figure 3-4 on page 3-14.
Accuracy of User-defined Limits
Current
0 to 5% over the limit from 10 to 100% of full
rated output
Voltage
0 to 5% over the limit from 10 to 100% of full
rated output
Power
0 to 10% over the limit from 2 kW to 10 kW
Table 3-3. Electrical Specifications (Continued)
