3-8 Specifications 5702269-C
Advanced Energy
®
50
50 9.0 2.00 45.0
55
54.945 8.1 2.20 44.5
60
60.06 7.4 2.40 44.4
65
64.935 6.9 2.60 44.8
70
69.93 6.4 2.80 44.8
75
74.906 6.0 3.00 44.9
80
80 5.6 3.20 44.8
85
85.106 5.2 3.40 44.3
90
90.09 4.9 3.60 44.1
95
94.787 4.7 3.79 44.5
100
100 4.5 4.00 45
105
105.263 4.2 4.21 44.2
110
109.89 4 4.40 44
115
114.943 3.9 4.60 44.8
120
119.76 3.7 4.79 44.3
125
125 3.6 5.00 45
130
129.87 3.4 5.19 44.2
135
135.135 3.3 5.41 44.6
140
139.86 3.2 5.59 44.8
145
144.928 3.1 5.80 44.9
150
150.376 2.9 6.02 43.6
155
155.039 2.9 6.20 45
160
160 2.8 6.4 44.8
165
165.289 2.7 6.61 44.6
170
169.492 2.6 6.78 44.1
175
175.439 2.5 7.02 43.9
Table 3-4. Reverse Time Given a Self-Run Frequency (Continued)
Requested
Frequency
(kHz)
Actual
Frequency
(kHz)
Pulse
Reversal Time
Maximum (µs)
Duty Cycle
(min%)
Reverse/
Period
Duty Cycle
(max%)
Reverse/
Period
