3-12 Specifications 5702269-C
Advanced Energy
®
390 8.3 µs
395 8.2 µs
400 8.1 µs
405 8 µs
410 7.9 µs
415 7.8 µs
420 7.7 µs
425 7.6 µs
430 7.5 µs
435 7.4 µs
440 7.3 µs
445 7.3 µs
450 7.2 µs
455 7.1 µs
460 7 µs
465 6.9 µs
470 6.9 µs
475 6.8 µs
480 6.7 µs
485 6.7 µs
490 6.6 µs
495 6.5 µs
500 6.5 µs
505 6.4 µs
510 6.3 µs
515 6.3 µs
520 6.2 µs
525 6.1 µs
530 6.1 µs
535 6 µs
540 6 µs
545 5.9 µs
550 5.9 µs
Table 3-5. Reverse Time as a Function of Voltage Limit (V-Limit)
V-Limit
(in Volts)
Corresponding Reverse Time
