TRANSMISSION

5-2

TRANSMISSION

TRANSMISSION ASSEMBLY

TRANSMISSION DISASSEMBLY AND

INSPECTION

NOTE: Engine removal is not required to service

transmission components. Process shown below is with

engine removed for clarity.

1. Drain the transmission oil from the gear case (A) and engine oil

from crankcase (B).

SHIFT SYSTEM REMOVAL

1. Remove right footwall.

2. Remove sprocket cover and drive sprocket.

3. Remove shift cables from the bracket.
