ELECTRICAL
9-8
SIGNAL
FRONT SIGNAL REPLACEMENT
If the headlights do not operate, lamp replacement may be
required. Install only the recommended replacement lamps
1. Take off the front signal wire plug from harness.
2. Remove front signal and bracket from cab as picture.
3. Remove rubber waterproof cap.
4. Remove socket fastener screw and lamp socket.
5. Remove and replace lamp.
6. Reinstall all front signal components.
REAR SIGNAL REPLACEMENT
1. Remove rear signal and bracket from cab as picture.
2. Use small blade drive screw to remove lens.
3. Remove all components and replace lamp.
4. Reinstall all rear signal components.
