Aeon COBRA 400 2012 User Manual

BRAKES
8-2
SPECIFICATIONS
GENERAL SPECIFICATIONS
Front Brake Disc
Item Standard Service Limit
Brake Pad Thickness
7.6 mm (0.298”) 4.3 mm (0.17”)
Brake Disc Thickness
4mm (0.16”) 3.5mm (0.14”)
Brake Disc Thickness Variance
Between Measurements
--
0.05mm (0.002”)
Brake Disc Run out
--
0.25mm (0.01”)
Rear Brake Disc
Item Standard Service Limit
Brake Pad Thickness
7.8 mm (0.20”) 4.5 mm (0.18")
Brake Disc Thickness
4.2 mm (0.17”) 3.8mm (0.15”)
Brake Disc Thickness Variance
Between Measurements
--
0.05mm (0.002”)
Brake Disc Run out
--
0.25mm (0.01”)
TORQUE SPECIFICATIONS
Item Torque
(Nm)
Torque
(ft. lbs. except where noted*)
Front Caliper Mounting Bolts
25 18
Rear Caliper Mounting Bolts
42 31
Master Cylinder Reservoir
Cover Bolts
0.6 5 in.lbs.
Brake Line Banjo Bolt
20 15
Brake Disc Mounting Bolts
29 21.4
Caliper Bleed Screws
3 27 in.lbs.
Foot Brake Master Cylinder Mounting
Bolt
25 18
Shunt Mounting Bolt
20 15
NOTE: Refer to the tightening procedures in this chapter when screw the bolts. Some special procedures are
used when screw certain bolts and fasteners.
