MAINTENANCE
2-9
FUEL SYSTEM AND AIR INTAKE
IDLE SPEED ADJUSTMENT
1. Start engine and warm it up thoroughly.
2. Adjust idle speed by turning the slide adjustment screw in
(clockwise) to increase or out (counterclockwise) to decrease
RPM. (Refer to illustration).
Idle Speed
1500 ± 100 r.p.m.
NOTE: Adjusting the idle speed affects throttle cable
free play. Always check throttle cable free play after
adjusting idle speed and adjust if necessary.
Fuel Line
1. Check the quick-connect fuel line for signs of wear,
deterioration, damage or leakage. Replace if necessary.
2. Be sure fuel line is routed properly.
IMPORTANT: Make sure line is not kinked or pinched.
3. Replace fuel line every two years.
Vent Lines
1. Check fuel tank, front gear case, and rear gear case and
transmission vent lines for signs of wear, deterioration,
damage or leakage. Replace every two years.
2. Be sure vent lines are routed properly and secured with
cable ties.
IMPORTANT: Ensure lines are not kinked or pinched.
Gasoline is extremely flammable and explosive
under certain conditions.
. Always stop the engine and refuel outdoors or in a
well-ventilated area.
. Do not smoke or allow open flames or sparks in or
near the area where refueling is performed or where
gasoline is stored.
. Do not overfill the tank.
. Fill the tank to the bottom of the filler neck.
. This will allow for thermal expansion.
. If you get gasoline in your eyes or swallow
gasoline, see your doctor immediately.
. If you spill gasoline on your skin or clothing,
immediately wash it off with soap and water and
change clothing.
. Never start the engine or run it in an enclosed area
Gasoline powered engine exhaust fumes are
poisonous and can cause loss of consciousness
and death in a short time.
