142 Operation
4510001 REV B – 220620
Run the new film down onto the Splicing Table to meet the end of the old film.
Looking at the beginning of the new film as it lays on the Splicing Table, find the halfway
point in the label design, and cut the old film across that point.
Open the cut in the new film to form a pocket, and squeeze in slightly on the end of the
old film so that it can fit into that pocket.
New
Film Roll
Beginning of
New Film Roll
End of Old
Film Roll
Running New Film Down Onto Splicing Table
Splicing Table
Halfway Through
Label Design
Cutting the Beginning of the New Film
10-15mm
Halfway Through
Label Design
Beginning of New Film End of Old Film
To Next Page
