Slide the end of the old film into that pocket in the beginning of the new film until the
design in the old film matches up with the design in the new film.
Carefully apply one layer of splicing tape over the location where the end of the new film
meets the old film to secure both pieces of film together. The tape should cover both
sides (top and bottom) of the flat film.
Sliding the Old Film into the New Film
Beginning of New Film End of Old Film
Pocket
Label Designs Align
in Overlap Area
Applying Splicing Tape and Cutting Air Holes
Beginning of New Film End of Old Film
Splicing
Tape
Punched
Holes
Where End of Old Film
Meets New Film
