66 Installation
4510001 REV B 220620
AFM-4510001-00177-01
Positioning the Timing Screw (View from Front)
Timing
Screw
LX-150
HMI
Conveyor
Product
Flow
Heat
Shrink
Tunnel
UR-1
Positioning the Timing Screw (View from Above)
LX-150
Heat
Shrink
Tunnel
UR-1
Timing
Screw
