220 Chapter 4
Assembly Replacement
Front Frame Subassemblies
Display Removal
CAUTION The new flat panel display comes with a protective plastic sheet over
the glass. Remove this plastic very slowly to avoid damage due to ESD.
CAUTION The surface of the display is very easily scratched. Avoid touching it
with your bare hands or other objects. Use a blower to remove any dust
from the display surface.
1. Refer to Figure 4-31. Unplug the backlight extension cables (5) from
the backlight connectors (6), and pull the cables out of the rubber
display mount. Carefully lay these cables away from the display.
2. Unplug the display flat flex cable (4) from the display connector. To
do this, you must first pull up on both sides of the locking
mechanism of the ribbon cable connector.
3. Remove the rubber mount that houses the display assembly from the
front frame.
4. Refer to Figure 4-34. Pull open the flaps of the rubber mount.
5. Remove the display shield board (1).
6. Now it is possible to carefully lift up on the display (2) to remove it
from the rubber mount.
