User Replaceable Parts
Replacement parts for the instrument are listed below. Unless otherwise shown, all parts are for the 34460A and
34461A models.
Part Number Description
34401-86020 Bumper Kit
33220-88304 Rear Bezel
34401-45021 Handle
33220-84101 Cover
5041-5228 Keypad
2090-1051 Display
2110-0817 Line Fuse (250 mA, 250 V, time delay)
2110-1547 Current Protection Fuse (3.15 A, 500 V, time delay)
2110-1402 Internal Fuse (11 A, 1000 V, fast acting)
34460-87910 Transformer
34401-45012 Terminal Latch
5041-5238 Power Module
34460-40201 Plastic Front Panel (34460A)
34461-40201 Plastic Front Panel (34461A)
53200-49311 Window
5041-5231 Front Panel Shield
5041-5225 Front/Rear Push Rod (34461A)
5041-5232 Fan (34461A)
1420-0356 Battery (in front panel)
Agilent Truevolt Series DMM Operating and Service Guide 297
