General Characteristics
This section lists the general characteristics of the instrument. Standards used to verify these include ISO/IEC
17025:2005 and ISO/IEC Guide 98-3:2008.
Line Power
Power Supply: 100 / 120 (127) / 220 (230) / 240 VAC ±10%, CAT II
Power Line Frequency: 50 / 60 / 400 Hz ±10%
Power Consumption: 25 VA
Environment
Operating Environment: Full accuracy for 0 °C to 55 °C
Full accuracy to 80% R.H. at 40 °C Non–condensing
Operating Altitude Up to 3000 m
Storage Temperature -40 to 70 °C
Mechanical
Rack Dimensions (W x H x D): 212.8 mm x 88.3 mm x 272.3 mm
Bench Dimensions (W x H x D): 261.2 mm x 103.8 mm x 303.2 mm
Weight (34460A): 3.68 kg (8.1 lbs)
Weight (34461A): 3.76 kg (8.3 lbs)
346 Agilent Truevolt Series DMM Operating and Service Guide
