Power-On and Reset State
These tables show factory default settings. Parameters marked with a bullet (•) are nonvolatile and are not affected by
power-on or system reset. Other parameters are volatile and are reset to the indicated values at power-on or after
*RST or SYSTem:PRESet.
The power-on/reset state may differ from these values if you have enabled power-on
state recall mode.
Measurement Configuration Factory Setting
Function DC Volts
Range Autorange (for all functions)
Resolution Resolution equivalent to 10 power-line cycles
(PLC).
Integration Time NPLC On, 10 PLC*
Autozero On*
Aperture Off, 1 second*
• Input Impedance • 10 MΩ (fixed for all DC voltage ranges)
AC Input Filter (bandwidth) 20 Hz (medium filter)
Temperature Transducer Type FRTD
RTD Reference Resistance 100 Ω
Nulls (individual functions) Off; reference set to 0.0 with auto reference
enabled (for all measurement functions)
* For all DC measurement functions.
Math Operations Factory Setting
Math State Disabled
Scale Function Null
Null and dB Relative Value Set to 0.0 with auto reference enabled
Upper and Lower Limits 0.0
Histogram Bin counts cleared; 100 bins; auto binning enabled
Statistics Cleared
• dBm Reference Resistance • 600 Ω
Triggering Operations Factory Setting
Trigger Count 1
Trigger Source Immediate
Trigger Delay Auto Delay
Sample Count 1
286 Agilent Truevolt Series DMM Operating and Service Guide
