DC Current 10 A Full Scale Calibration (34461A only)
Review Test Considerations and Flatness Adjustment Considerations before beginning this procedure.
Configuration: DC Current
1. Configure the 10 A range and 100 PLC aperture.
2. Apply the 5 A input.
3. Enter the actual applied input current as the Cal Value (see Entering Adjustment Values). A Calibration Step
Succeeded message indicates success; if the display shows Calibration Step Failed, check the input value, range,
function, and entered adjustment value and repeat the adjustment step.
4. Store the new calibration constants (see Storing the Calibration Constants).
5. Verify the AC Current Flatness adjustments.
This calibration takes less than 4 seconds to complete.
344 Agilent Truevolt Series DMM Operating and Service Guide
