Entering Adjustment Values and Storing Calibration Constants
Selecting the Adjustment Mode
Use the CALibration:ADC? query to begin ADC calibration. The response to this query indicates a successful adjustment
(0) or a failure (1). Following the ADC calibration, use the measurement commands to set the DMM measurement
parameters and functions for the mode being calibrated.
Front Panel: [Utility] > Test/Admin > Calibrate > Perform Cal > Cal Value > Perform ADC Cal
Entering Adjustment Values
To enter a calibration value from the remote interface use CALibration:VALue <value> followed by the CALibration?
query. The response to the query indicates whether the adjustment is valid.
Front Panel: [Utility] > Test/Admin > Calibrate > Perform Cal > Cal Value > (enter value) > Perform
Cal Step
Storing the Calibration Constants
To store calibration values in non-volatile memory, use CALibration:STORe.
Front Panel: [Utility] > Test/Admin > Calibrate > Save Cal Values
You must have performed a successful calibration immediately before pressing Save Cal Values.
330 Agilent Truevolt Series DMM Operating and Service Guide
