Math - Limits
Limit checking indicates how many samples have exceeded specified limits and visually indicates when the limits are
exceeded.
Front-Panel Menus
The limits menu is accessed from the [Math] menu.
The first softkey enables or disables limits. The second and third softkeys specify the limits either as high and low values
or as a span around a center value. For example, a Low limit of -4 V and a High limit of +7 V are equivalent to a
Center of 1.5 V and a Span of 11 V.
The Beeper softkey enables or disables beeping when limits are violated, and Clear Condition resets the limit borders
to green, as described below.
Agilent Truevolt Series DMM Operating and Service Guide 57
