DC Current Gain Calibration
Review Test Considerations and Gain Adjustment Considerations before beginning this procedure.
Configuration: DC Current
1. Configure each function and range in the order shown in the table below.
2. Apply the input signal shown in the Input column.
3. Enter the actual applied input current as the Cal Value (see Entering Adjustment Values).A Calibration Step
Succeeded message indicates success; if the display shows Calibration Step Failed, check the input value, range,
function, and entered adjustment value and repeat the adjustment step.
4. Repeat steps 1 through 3 for each gain adjustment point shown in the table.
5. Store the new calibration constants (see Storing the Calibration Constants).
6. Verify the DC Current Gain adjustments.
Each range takes less than 4 seconds to complete.
Instrument Settings
Input Function Range
100 µA DC Current 100 µA
1 mA 1 mA
10 mA 10 mA
100 mA 100 mA
1 A 1 A
342 Agilent Truevolt Series DMM Operating and Service Guide
