DC Voltage Gain Calibration
Review Test Considerations and Gain Adjustment Considerations before beginning this procedure.
Configuration: DC Voltage
1. Configure each function and range in the order shown in the table below.
2. Apply the input signal shown in the Input column.
3. Enter the actual applied input voltage amplitude (see Entering Adjustment Values). A Calibration Step Succeeded
message indicates success; if the display shows Calibration Step Failed, check the input value, range, function, and
entered adjustment value and repeat the adjustment step.
4. Repeat steps 1 through 3 for each gain adjustment point shown in the table.
5. Store the new calibration constants (see Storing the Calibration Constants).
6. Verify the DC Voltage Gain adjustments.
Each range takes less than 4 seconds to complete.
Instrument Settings
Input Function Range
10 V DCV 10 V
-10 V 10 V
0.1 V 100 mV
-0.1 V 100 mV
1 V 1 V
100 V 100 V
1000 V 1000 V
340 Agilent Truevolt Series DMM Operating and Service Guide
