Finishing Adjustments

To finish adjusting your instrument:

1. Remove all shorting blocks and connections from the instrument.

2. Reset the calibration message.

3. Secure the instrument with the calibration password.

4. Record the new calibration count.

Agilent Truevolt Series DMM Operating and Service Guide 345
