*RCL {0|1|2|3|4}
*SAV {0|1|2|3|4}
Stores the current instrument state to, or recalls the instrument state from, the state file STATE_<n>.sta in the root
folder of the internal flash file system, where <n> is the number specified.
Parameter Typical Return
{0|1|2|3|4} (none)
Store the instrument state to the state file STATE_1.sta in the root folder of the internal flash file system.
*SAV 1
l *SAV <n> is equivalent to MMEMory:STORe:STATe "INT:\STATE_n.sta".
l *RCL <n> is equivalent to MMEMory:LOAD:STATe "INT:\STATE_n.sta".
l The state file created by *SAV 0, called STATE_0.sta, resides in the root folder of the internal flash file system. It is
overwritten with the power-down state of the instrument when power is cycled.
l The instrument state enable settings are stored in nonvolatile memory. They do not change when power has been
off, after a Factory Reset (*RST) or after an Instrument Preset (SYSTem:PRESet).
*RST
Resets instrument to factory default state, independent of MMEMory:STATe:RECall:AUTO setting. This is similar to
SYSTem:PRESet. The difference is that *RST resets the instrument for SCPI operation, and SYSTem:PRESet resets the
instrument for front-panel operation. As a result, *RST turns the histogram and statistics off, and SYSTem:PRESet
turns them on (CALC:TRAN:HIST:STAT ON).
Parameter Typical Return
(none) (none)
Reset the instrument:
*RST
l Does not affect stored instrument states (see *SAV).
Agilent Truevolt Series DMM Operating and Service Guide 159
