Step 4: Press AC Filter and choose the filter for the measurement. The instrument uses three different AC filters that
enable you either to optimize low frequency accuracy or to achieve faster AC settling times following a change in input
signal amplitude.
The three filters are 3 Hz, 20 Hz, and 200 Hz, and you should generally select the highest frequency filter whose
frequency is less than that of the signal you are measuring, because higher frequency filters result in faster
measurements. For example, when measuring a signal between 20 and 200 Hz, use the 20 Hz filter.
If measurement speed is not an issue, choosing a lower frequency filter may result in quieter measurements,
depending on the signal that you are measuring.
For accurate displayed statistics of AC measurements in Front Panel mode, the default manual trigger
delay ([Acquire] > Delay Man) must be used.
38 Agilent Truevolt Series DMM Operating and Service Guide
