Power On

Power On selects the state that is loaded at power-up. This can be either the state when the instrument was powered

down with the power switch (Last), a user-selected state file (User Defined), or the factory default state (Factory

Defaults).

Set to Defaults

Set to Defaults loads the instrument's factory default state or preference settings.

Agilent Truevolt Series DMM Operating and Service Guide 71
