143
User Guide
EQ
Digital EQ
This is a monaural, three-band parametric equalizer.
• EQ Freq 1 (20Hz - 20kHz) Sets the center frequency for EQ1
• Gain 1 (-18dB - +18dB) Adjusts the gain for EQ1
• EQ Freq 2 (20Hz - 20kHz) Sets the center frequency for EQ2
• Gain 2 (-18dB - +18dB) Adjusts the gain for EQ2
• EQ Freq 3 (20Hz - 20kHz) Sets the center frequency for EQ3
• Gain 3 (-18dB - +18dB) Adjusts the gain for EQ3
Pressing the [F5] MORE softkey accesses additional parameters:
• Q 1 (0.5 - 10) Sets the Q for EQ1
• Q 2 (0.5 - 10) Sets the Q for EQ2
• Q 3 (0.5 - 10) Sets the Q for EQ3
• Output (-24dB - +24dB)
Offsets the ouput level of the EQ'ed sound
ENHANCER
Enhancer
This monaural effect gives frame to the sound by adding new overtones.
• Drive (0dB - 30dB) Adjusts the gain of the signal input to the harmonics generator
• Tune (0% - 100% ) Adjusts the filter cut-off frequency
• Damp (0% - 100% )
Adjusts the filter attenuation curve (slope)
• Harm (0% - 100% )
Adjusts the signal level of the emphasized harmonics
DISTORTION
Distortion
This monaural distortion effect distorts input signals.
An equalizer is connected to the effect in series.
• Depth (0dB - 24dB) Adjusts the depth of distortion
• EQ freq (1000Hz - 2000Hz) Adjusts the center frequency of the EQ
• EQ Gain (-15dB - +15dB) Adjusts the gain of the EQ
• EQ (0.5 - 10) Adjusts the Q of the EQ
EQ
