Information Meaning
Module Type Derived from SFP SEEPROM information.
• NOT AVAILABLE
• STM-1
• STM-1/STM-4
• STM-4
• STM-16
• GbE
• UNKNOWN
Apparatus / Item Code The Apperatus / Item Code is a 12 byte character
string.
Example: OM16CS59
Interchangeablility Marker The Interchangeablility Marker is a 6 byte
character string, left aligned and padded on the
right with ASCII spaces (20HEX)
Buttons and Actions
The following options are available:
If you select ... Then ...
Unassign Unassigns the pluggable module.
Update Allows you to update the current view or dialog with the
most recent information. If a dialog has been open for a
while, the data displayed may not still be current. The Update
button allows you to obtain the most recent information.
Close Closes the window.
