Alarm identifier
“Probable cause”
Alarm text Alarm
severity
Reporting state
(default setting)
UPUS Unit present in unassigned slot Information Reported
X21XcEQF X.21 interface extension board - defective Prompt Reported
X21XcWUP Wrong X.21 interface extension board
inserted
Prompt Reported
X21XcUNI X.21 interface extension board missing Prompt Reported
X21XcUPF X.21 interface extension board - defective Prompt Reported
Notes:
1. Alarms marked with an asterisk (“*”) in the “Probable cause” column are not supported
in the present 1643 AM release. These alarms are prepared for future applications.
mdi ASAP
The following table lists the default alarm severity assignments of the “mdi” ASAP.
Alarm identifier
“Probable
cause”
1
Alarm text
2
Alarm
severity
Reporting state
(default setting)
MDcIP1 MDI 1: <user entered string> Information Reported
MDcIP2
MDI 2: <user entered string> Information Reported
MDcIP3 MDI 3: <user entered string> Information Reported
MDcIP4 MDI 4: <user entered string> Information Reported
RPSMDcIP1 MDI 1 located on the remote power supply box -
indicates an environmental alarm condition
Deferred Reported
RPSMDcIP2 MDI 2 located on the remote power supply box -
indicates an environmental alarm condition
Deferred Reported
RPSMDcIP3 MDI located on the remote power supply box -
indicates an environmental alarm condition
Deferred Reported
Notes:
1. In the ITM CIT NE Alarm List, only “MISC” is displayed as the probable cause of an
environmental alarm.
2. You can change the alarm text of each individual Miscellaneous Discrete Input (MDI).
Alarm management
Alarm Severity Assignment Profile
....................................................................................................................................................................................................................................
6-50
Alcatel-Lucent - Proprietary
See notice on first page
365-312-807R7.2
Issue 4, May 2007
