Result: The SDH channel / VCG Information window is now populated with
information for this port.
Refer to “Parameters of the window “View SDH Channel / VCG Information””
(p. 8-102).
...................................................................................................................................................................................................
14
For provisioning the basic Ethernet and VCG port parameters to be used for this port
click on
Edit.
Result:
The Edit SDH Channel / VCG Information window is opened.
...................................................................................................................................................................................................
15
Set the
•
Encapsulation Mode to Generic Framing Procedure
•
LCAS Mode to Enabled or Disabled
• TP Mode to Monitored or Not Monitored and
•
VC Type to VC3 or VC12
from the drop down list and then click
Ok.
Result: The Edit SDH Channel / VCG Information window is closed.
...................................................................................................................................................................................................
16
IF THEN
you want to provison a virtual
switch in spanning tree mode
(provided that the tagging mode
was set to standard VLAN
tagging in Step 9 of this
procedure)
continue with “Provisioning a virtual switch in
spanning tree mode” (p. 8-105)
you want to provison a virtual
switch in repeater mode
(provided that the tagging mode
was set to transparent tagging ,
also known as double tagging or
VPN tagging, in Step 9 of this
procedure)
continue with “Provisioning a virtual switch in
repeater (promiscuous) mode ” (p. 8-103)
you want to provision a virtual
switch in provider bridge mode,
(provided that the tagging mode
was set to IEEE 802.1ad , in
Step 9 of this procedure)
continue with “Provisioning a virtual switch in
spanning tree mode” (p. 8-105)
E ND OF STEPS
...................................................................................................................................................................................................
