Alcatel-Lucent 5620 - Logviewer GUI

6 — 5620 SAM LogViewer
Alcatel-Lucent 5620 Service Aware Manager, Release 6-3
3HE 05723 TQZZA Edition 01 Troubleshooting Guide
6.2 LogViewer GUI
The LogViewer GUI opens to display a Quick Links panel that has shortcuts to the
logs that are present on the local file system. When you click on a log shortcut,
LogViewer opens a tab that displays the most recent log entries. Figure 6-1 shows
the LogViewer GUI with the Quick Links panel displayed and describes the main
tool bar buttons.
Figure 6-1 LogViewer GUI showing Quick Links panel
Overview
Each log that you open using the LogViewer GUI is displayed on a separate tab
whose label contains the name of the log profile and an icon that indicates the log
type. The log entries are highlighted using the colors configured for the log debug
levels. A log tab that displays dynamic log updates also has a tool bar for common
operations.
Figure 6-2 shows the LogViewer GUI with multiple open logs and describes the tool
bar buttons on a tab that displays a currently active log.
Open
log
Save
configuration
Reload
configuration
Clear
configuration
Export log
properties
Import log
properties
Edit
log
Find
Find
next
Application
options
Change
highlight colors
Manage
filters
Add
filter
Edit
filter
Add to Filter
Manager
Create from
entry
Clear
selected
LogViewer
log
About
LogViewer
19865
Remove
filter
Create from
quick
Clear all
