3 — Troubleshooting using network alarms
3-50 Alcatel-Lucent 5620 Service Aware Manager, Release
Troubleshooting Guide 3HE 05723 TQZZA Edition 01
Table 3-18 Domain: file
Table 3-19 Domain: generic
Name: apsNoRspRaiseAlarm
Type: configurationAlarm (11)
Probable cause:
incompleteProtectionSwitching (549)
Severity: Major
Object Type (class):
EthernetTunnelEndpoint
Domain: ethernettunnel
Implicitly cleared (self-clearing): Yes
The alarm is raised when an Ethernet
tunnel group protection switch is
incomplete, as indicated by a
comparison of the transmitted
'Requested Signal' values and the
received 'Bridged Signal' in the APS
protocol.
Name: apsPrvsnRaiseAlarm
Type: configurationAlarm (11)
Probable cause: provisioningMismatch (470)
Severity: Major
Object Type (class):
EthernetTunnelEndpoint
Domain: ethernettunnel
Implicitly cleared (self-clearing): Yes
The alarm is raised when an Ethernet
tunnel group provisioning mismatch
is detected at the ETH layer. The
mismatch is detected through a
comparison of the transmitted and
received APS protocol A, B and D
bits.
Name: EthernetTunnelDown
Type: configurationAlarm (11)
Probable cause: ethernetTunnelDown (547)
Severity: Major
Object Type (class): EthernetTunnel
Domain: ethernettunnel
Implicitly cleared (self-clearing): Yes
The alarm is raised when the
aggregated Ethernet tunnel
Operational State is Down.
Alarm Attributes Additional information
Name: LogLocFailure
Type: storageAlarm (25)
Probable causes:
• AdminLocFailure (244)
• BackupLocFailure (245)
Severity: Variable or indeterminate
Object Type (class): Policy
Domain: file
Implicitly cleared (self-clearing): No
The alarm is raised when an attempt
to create a log or billing file fails.
The probable cause is
AdminLocFailure when using the
admin location fails, in which case
the backup location, if specified, is
used. The probable cause is
BackupLocFailure when using the
backup location fails.
Alarm Attributes Additional information
Name: DeploymentFailure
Type: deploymentFailure (5)
Probable cause:
failedToModifyNetworkResource (11)
Severity: Minor
Object Type (class): GenericObject
Domain: generic
Implicitly cleared (self-clearing): Yes
The alarm is raised when the
5620 SAM is unable to create,
modify, or delete a network object
because of NE unreachability or a
failed SNMP set operation. The alarm
information includes the deployment
ID, the requesting user ID, and the
deployment type.
Name: ThresholdCrossingAlarm
Type: thresholdCrossed (6)
Probable cause: thresholdCrossed (12)
Severity: Warning
Object Type (class): GenericObject
Domain: generic
Implicitly cleared (self-clearing): Yes
The alarm is raised when a
monitored object statistics-counter
value exceeds a threshold value in
the associated statistics policy.
(1 of 2)
Alarm Attributes Additional information
(2 of 2)
