IP Router Configuration
Router Configuration Guide 291
Sample Output
*A:Dut-B#config>service>vprn# show router 1 route-table
===============================================================================
Route Table (Service: 1)
===============================================================================
Dest Prefix[Flags] Type Proto Age Pref
Next Hop[Interface Name] Metric
-------------------------------------------------------------------------------
10.0.0.0/30 Local Local 02h09m23s 0
to_4007 0
10.0.0.8/30 Remote BGP VPN 00h06m38s 170
1.1.1.9 (tunneled) 0
11.0.0.8/30 Remote BGP VPN 00h06m38s 170
1.1.1.9 (tunneled) 0
192.168.0.0/16 [E] Remote BGP VPN 00h06m38s 170
1.1.1.9 (tunneled) 0
192.168.0.0/16 [E] Remote BGP VPN 00h06m38s 170
2.1.1.9 (tunneled) 0
-------------------------------------------------------------------------------
No. of Routes: 4
Flags: L = LFA nexthop available B = BGP backup route available
E = best-external BGP route available
n = Number of times nexthop is repeated
===============================================================================
*A:Dut-B#config>service>vprn# show router 1 route-table alternative
===============================================================================
Route Table (Service: 1)
===============================================================================
Dest Prefix[Flags] Type Proto Age Pref
Next Hop[Interface Name] Metric
Next Hop The next hop IP address for the route destination.
Type Local
The route is a local route.
Remote
The route is a remote route.
Protocol The protocol through which the route was learned.
Age The route age in seconds for the route.
Metric The route metric value for the route.
Pref The route preference value for the route.
No. of Routes The number of routes displayed in the list.
Table 23: Standard Route Table Field Descriptions (Continued)
Label Description
