Product information and planning
MPR-e 105
MPR-A: Maximum allowed cable length for MPT Extended
Power Unit
MPR-E parts lists
Indoor items
Table 31 provides codes for indoor items.
Table 30: Maximum allowed cable lengths for MPT Extended Power Unit (MPR-A)
Cable type Cat5E,
1AC016760006:
Power and Data on
Ethernet cable
Cat5E,
1AC016760006:
Power only, Data
on optical cable
Coaxial cable
1AB350440001:
Power only, Data
on optical cable
Configuration Maximum length Maximum length Maximum length
MPT-MC/HC 100 m 100 m 300 m
MPT-HC V2 with XPIC 100 m 100 m 300 m
MPT-XP 100 m 100 m 300 m
MPT-XP with XPIC 100 m 100 m 300 m
Constraint 1 Maximum current in Ethernet transformer
< 1.8 A
Maximum current limit for Power Unit:
1.8 A
Maximum current
limit for Power
Unit: 1.8 A
Constraint 2 Minimum MPT-HC PSU input voltage > 28 V, Minimum MPT-
XP PSU input voltage > 36 V
Constraint 3 Data traffic only
with Ethernet cable
Data traffic only
with optical cable
Table 31: MPR-E: Indoor items
Name Part number Remarks
