MPT-HC V2 with internal diplexer
Table 35: MPR-E: MPT-HC V2 with internal diplexer
Band (GHz) Shifter (MHz) Tx sub-band Part number Tx frequency (MHz)
L6 252.04 1 3DB20441BAXX 5929.96-6050
1P 3DB20443BAXX 6182-6302.04
2 3DB20442BAXX 6047.96-6168
2P 3DB20444BAXX 6300-6420.04
U6 340 1 3DB20437BAXX 6420-6600
1P 3DB20439BAXX 6760-6940
2 3DB20438BAXX 6565-6720
2P 3DB20440BAXX 6905-7060
3 3DB20464BAXX 6595-6775
3P 3DB20465BAXX 6935-7115
11 490
530
1 3DB20371BAXX 10695-10955
1P 3DB20547BAXX 11205-11485
2 3DB20546BAXX 10935-11205
2P 3DB20548BAXX 11445-11705
1 3DB20371BBXX 10695-10961
1P 3DB20547BBXX 11199-11485
2 3DB20546BBXX 10933-11200
2P 3DB20548BBXX 11430-11705
13 266 1 3DB20372BAXX 12750-12865
1P 3DB20420BAXX 13016-13131
2 3DB20419BAXX 12861-12980
2P 3DB20421BAXX 13127-13246
