Functional description
168 MPR-e
On the MPR-e side, the MPR-e that is connected to the 7705 SAR-8 or 7705 SAR-18 must
have PCR enabled and the source and destination MAC addresses of the 7705 SAR-8 or
7705 SAR-18 must be configured as shown in
Table 75: 7705 SAR PMC card MAC addresses
SAR slot
#
PMC port # Source MAC address Destination MAC address
1 1 00-80-9F-09-F1-11 00-80-9F-09-F1-01
2 00-80-9F-09-F1-21
3 00-80-9F-09-F1-31
4 00-80-9F-09-F1-41
2 1 00-80-9F-09-F2-12 00-80-9F-09-F2-02
2 00-80-9F-09-F2-22
3 00-80-9F-09-F2-32
4 00-80-9F-09-F2-42
3 1 00-80-9F-09-F3-13 00-80-9F-09-F3-03
2 00-80-9F-09-F3-23
3 00-80-9F-09-F3-33
4 00-80-9F-09-F3-43
4 1 00-80-9F-09-F4-14 00-80-9F-09-F4-04
2 00-80-9F-09-F4-24
3 00-80-9F-09-F4-34
4 00-80-9F-09-F4-44
5 1 00-80-9F-09-F5-15 00-80-9F-09-F5-05
2 00-80-9F-09-F5-25
3 00-80-9F-09-F5-35
4 00-80-9F-09-F5-45
