Product information and planning
MPR-e
71
The two MPT-HC V2/9558HC units must
also
be interconnected through two terminated
cables (XPIC and RPS cables) as shown in
Figure
21
,
Figure
22
, and
Figure
23
.
Figure
21:
MPT-HC V2/9558HC connection through the Powe
r Injector Box (co-
channel XPIC)
Note:
The extra length of the RPS
and XPIC cables must be
bound by using tie
-wraps,
either on the pole or on the other
cables coming from the ODUs.
70
72
